20’ x 8’ Refrigerated ISO Container
Part Number: SB533.0
Type: IRefrigerated ISO Cargo Container. Double doors on one End.
SB533.0 BrochureIf your storage or transportation needs are more unique, SEA BOX can create custom sized containers to accommodate any need.
Request a Quote
- Aluminum, steel or sides
- Double full opening swing doors on one end
- Forklift pockets (on some 20' units)
- Aluminum T-grade floors
- Most refrigerated machinery features electrical supply as follows: 208/230, 380/460 Volts AC, 3 phase, 50 or 60 cycle
- Temperature range from -20°F to 70°F
ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD
| Length | Height | Width | Door Opening | |||||
| Exterior | Interior | Exterior | Interior | Exterior | Interior | Height | Width | |
| Ft in | 19' 10 1/2" | 17' 5 1/2" | 8’ 0” | 6' 10 1/2" | 8’ 0” | 7' 4" | 6' 10 1/2" | 7' 4" |
| Metric | 6,058 | 5,321 | 2,438 | 2,096 | 2,438 | 2,235 | 2,096 | 2,235 |
| TARE WEIGHT | PAYLOAD | GROSS WEIGHT | CUBIC CAPACITY | |
| Lbs | 6,480 | 60,720 | 67,200 | 880 Cu. Ft. |
| Kgs | 2,940 | 27,540 | 30,480 | 24.9 Cu. M. |
ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
