Standard Features

  • Aluminum, steel or sides
  • Double full opening swing doors on one end
  • Forklift pockets (on some 20' units)
  • Aluminum T-grade floors
  • Most refrigerated machinery features electrical supply as follows: 208/230, 380/460 Volts AC, 3 phase, 50 or 60 cycle
  • Temperature range from -20°F to 70°F

Optional Features

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 19' 10 1/2" 17' 5 1/2" 8’ 0” 6' 10 1/2" 8’ 0” 7' 4" 6' 10 1/2" 7' 4"
Metric 6,058 5,321 2,438 2,096 2,438 2,438 2,096 2,235
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 6,480 60,720 67,200 880 Cu. Ft.
Kgs 2,940 27,540 30,480 24.9 Cu. M.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
