Standard Features

  • Corrugated steel sides and roof
  • 14 gauge locking steel double end swing doors
  • 1 1/8” thick marine plywood floors, forklift tested to 16,000 lbs per 44 square inches
  • Wall tie down steel lashing rings, 6,000 lbs. cap. each
  • Front corner post tie downs
  • Door corner post tie downs = restraint system, shoring slot will support 2” x 6” lumber
  • Vents, (2) each

Optional Features

  • Manifest box (2) each
  • Adjustable shelving brackets (12) sets
  • Decking and shoring beams (36) each

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 45’ 0” 44’ 5 3/4” 9’ 6” 8’ 10 1/16” 8’ 0” 7’ 8 1/2” 8’ 5 3/4” 7’ 8 1/16”
Metric 13,716 13,557 2,896 2,694 2,438 2,438 2,585 2,338
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 10,210 56,990 67,200 3,040 Cu. Ft.
Kgs 4,631 25,849 30,480 86.1 Cu. M.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
