40’ x 8’6” Open Top Cargo Container
Part Number: SB6432
Type: I40' x 8'6" Open Top Cargo Container
Double doors on one End.
SB6432 BrochureIf your storage or transportation needs are more unique, SEA BOX can create custom sized containers to accommodate any need.
Request a Quote
- 14 gauge corrugated steel sides
- 14 gauge locking steel double end swing doors
- 1 1/8” thick marine plywood floors, forklift tested to 16,000 lbs per 44 square inches
- Tie down steel lashing rings, 4000 lbs. cap. each
- (19) roof bows with heavy duty roof tarp
- Security roof tarp locking cable
- Top Opening Dimensions: Length: 38' 11 3/8"/11,871, Width: 7' 2 3/16/2,189
- Removable hard lid
ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD
| Length | Height | Width | Door Opening | |||||
| Exterior | Interior | Exterior | Interior | Exterior | Interior | Height | Width | |
| Ft in | 40’ 0” | 39’ 5 5/8” | 8’ 6” | 7’ 9 3/16” | 8’ 0” | 7’ 8 1/2” | 7’ 5 5/8” | 7’ 8 1/16” |
| Metric | 12,192 | 12,030 | 2,591 | 2,367 | 2,438 | 2,350 | 2,277 | 2,338 |
| TARE WEIGHT | PAYLOAD | GROSS WEIGHT | CUBIC CAPACITY | |
| Lbs | 9,150 | 58,050 | 67,200 | 1,130 Cu.Ft. |
| Kgs | 4,150 | 26,330 | 30,480 | 32 Cu.M. |
ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
