Standard Features

  • Corrugated steel sides, roof, and functional swing doors on both sides
  • Heavy-duty steel floor
  • Four-way fork lift pockets
  • Wall tie down steel lashing rings, 2,000 lbs. cap., tested at 3,000 lbs. each, (16) total
  • Vents, (2) each in door panels

Optional Features

  • Connecting couplers, (3) per Quadcon
  • Connecting coupler storage bracket, (1) each

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 4’ 9 3/8” 4’ 7 3/4” 6’ 10” 6’ 3 1/16” 8’ 0” 7’ 6 9/16” 5’ 11 3/16” 4’ 5 5/8”
Metric 1,457 1,417 2,083 1,907 2,438 2,438 1,808 1,362
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 2,000 9,200 11,200 220 Cu. Ft.
Kgs 907 4,173 5,080 6.22 Cu. M.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
