Standard Features

  • Corrugated steel sides and roof
  • (1) 14 gauge locking steel double swing doors on 10’ side
  • Steel floors, forklift tested to 16,000 lbs. per 44 square inches
  • Tie down steel lashing rings, 4,000 lbs. cap. each
  • (4) way forklift pockets
  • Vents, (2) each

Optional Features

  • Connecting couplers, (2) per Bicon
  • Connecting coupler storage bracket, (1) each
  • Manifest box, (2) each
  • Heavy duty adjustable shelving brackets (4) sets
  • Decking and shoring beams, (16) each

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 9’ 9 3/4” 9’ 3 1/2” 8’ 0” 7’ 5 1/64” 8’ 0” 7’ 8 17/32” 7’ 6” 9’ 5 1/2”
Metric 2,991 2,832 2,438 2,261 2,438 2,438 2,286 2,883
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 3,000 13,000 16,000 517 Cu. Ft.
Kgs 1,361 5,897 7,258 15.9 Cu. M.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
