Standard Features

  • Corrugated steel sides and roof
  • 14 gauge locking steel double end swing doors
  • Steel floor
  • (6) Tie down steel lashing rings, 6,000 lbs. cap. each
  • (4) way fork lift pockets
  • Vents, (2) each
  • (2) double side door (2) Bicon Containers coupled together to form (1) 20’ ISO module
  • (2) double side door (2) Bicon Containers coupled together to form (1) 20’ ISO module

Optional Features

  • Connecting couplers, (2) per Bicon
  • Connecting coupler storage bracket, (1) each
  • Manifest box, (2) each
  • Heavy duty adjustable shelving brackets (4) sets
  • Decking and shoring beams, (16) each

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 9’ 9 3/4” 9’ 7 43/64” 8’ 0” 7’ 11 3/64” 8’ 0” 7’ 3 61/64” 7’ 7 1/16” 9’ 5 57/64”
Metric 2,991 2,938 2,438 2,414 2,438 2,438 2,313 2,893
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 3,970 22,490 26,460 559 Cu. Ft.
Kgs 1,800 10,200 12,000 15.84 Cu. M.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
