20’ x 8’6” in Dry Freight ISO Container Type 2
Part Number: SB862.6
NSN: 8145-01-551-3128, 8150-01-551-3126
Type: IISEA BOX offers a large selection of 20' ISO dry freight storage containers for military and commercial use. Also known as a Conex Box or Milvan, our 20' ISO dry freight storage containers come in several different heights with various door configurations and are available in standard or custom colors with or without Chemical Agent Resistant Coating (CARC) paint. SEA BOX 20' ISO dry freight containers are available for sale or rent and are ideal for for temporary storage or permanent storage. We have a large inventory of new and used 20' containers and are easily transportable via land, air, and sea and can be modified or customized to accommodate virtually any type of cargo.
SB862.6 Brochure
- Corrugated steel sides, roof, and swing doors on both ends
- Two-way laden forklift pockets
- 1 1/8” thick marine plywood floors, forklift tested to 16,000 lbs per 44 square inches
- Wall tie down steel lashing rings, 6,000 lbs. cap. each (24 total)
- Door corner post tie downs, (20) total = restraint system, shoring slot will support 2” x 6” lumber
- Vents, (2) each
- Manifest box (2) each
- 2nd set unladen forklift pockets
- 383 Green exterior CARC paint
ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD
| Length | Height | Width | Door Opening | |||||
| Exterior | Interior | Exterior | Interior | Exterior | Interior | Height | Width | |
| Ft in | 19’ 10 1/2” | 19’ 2 5/64” | 8’ 6” | 7’ 10 3/8” | 8’ 0” | 7’ 8 19/32” | 7’ 6 1/32” | 7’ 8 1/8” |
| Metric | 6,058 | 5,844 | 2,591 | 2,397 | 2,438 | 2,352 | 2,287 | 2,340 |
| TARE WEIGHT | PAYLOAD | GROSS WEIGHT | CUBIC CAPACITY | |
| Lbs | 5,020 | 62,180 | 67,200 | 1,163 Cu. Ft. |
| Kgs | 2,277 | 28,203 | 30,480 | 32.94 Cu. M. |
ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
