Standard Features

  • Corrugated steel ends, side, and bifold swing door on the side
  • (2) sets of forklift pockets, laden and unladen
  • 1 1/8” thick marine plywood floors, forklift tested to 16,000 lbs per 44 square inches
  • Wall tie down steel lashing rings, 6,000 lbs. cap. each
  • Corner post tie downs
  • Floor recessed tie downs
  • Vents, (2) each

Optional Features

  • Manifest box (2) each
  • 383 Green exterior CARC paint

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 19' 10 1/2" 19' 6 1/4" 8’ 0” 6’ 11 3/16” 8’ 0” 7' 6 1/16" 6’ 6 5/16” 18' 5"
Metric 6,058 5,950 2,438 2,113 2,438 2,438 1,989 5,613
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 6,430 46,480 52,910 1,016 cu. ft.
Kgs 2,917 21,083 24,000 28.8 cu. m.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
