Standard Features

  • Corrugated steel ends, side, and bifold swing door on the side
  • (2) sets of forklift pockets, laden and unladen
  • 1 1/8” thick marine plywood floors, forklift tested to 16,000 lbs per 44 square inches
  • Wall tie down steel lashing rings, 6,000 lbs. cap. each
  • Corner post tie downs
  • Floor recessed tie downs
  • Vents, (2) each

Optional Features

  • E-track bracket system
  • Heavy-duty adjustable shelving brackets (8) sets
  • Decking and shoring beams

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 19' 10 1/2" 19' 6 11/32" 8’ 6” 7’ 5 11/64” 8’ 0” 7' 6 43/64" 7' 0 17/32" 19' 5 25/32"
Metric 6,058 5,952 2,591 2,265 2,438 2,438 2,147 5,958
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 6,530 46,380 52,910 1,094 cu. ft.
Kgs 2,960 21,040 24,000 31.0 cu. m.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
