Standard Features

  • Corrugated steel sides, roof, and swing doors on both sides
  • Heavy-duty steel floor
  • Four-way fork lift pockets
  • Adjustable shelving brackets, (5) sets = (10) vertical E-track sections total
  • Wall tie down steel lashing rings, 4,000 lbs. cap. Each (16) total
  • Door corner post tie downs, (20) total = restraint system shoring slot will support 2” x 6” lumber
  • Vents, (2) each in door panels
  • Connecting couplers, (3) per Quadcon
  • Connecting coupler storage bracket, (1) each

Optional Features

  • 383 Green or 33446 Tan exterior CARC paint

Container Specs

ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD

Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 4’ 9 3/8” 4’ 6” 8’ 0” 7’ 5” 8’ 0” 7’ 6 9/16” 7’ 1 1/8” 4’ 5 1/2”
Metric 1,457 1,404 2,438 2,261 2,438 2,438 2,163 1,359
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs 2,120 9,040 11,200 258 Cu. Ft.
Kgs 960 4,100 5,080 7.3 Cu. M.

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
